Performanță
Connectivity technology	Wired
Placement supported	Outdoor
Type	IP security camera
Day/night mode	Yes
Certification	EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(B), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835
PTZ control	Yes
Wide Dynamic Range (WDR)	Yes
Languages support	CHI (SIMPL),CHI (TR),CZE,DEU,DUT,ENG,ESP,FIN,FRE,ITA,JPN,KOR,POR,RUS,SWE,THA,TUR,VIE
Infrared (IR) cut-off filter	Yes
Number of languages	18
Tour recording	Yes
Auto-tracking	Yes
Processor model	ARTPEC-7
Built-in processor	Yes

Design

Product colour Grey Form factor Box Mounting type Wall International Protection (IP) code IP66, IP68 Housing material Aluminium IK code IK10

Aparat de fotografiat

Minimum illumination 0.05 lx Camera shutter speed 1/111000 - 1/2 s Tilt angle range -90 - 90 ° Camera tilt control Yes Camera pan control Yes Pan speed 150 °/sec Tilt speed 150 °/sec Lens viewing angle, horizontal 63.8 ° Lens viewing angle, vertical 37 °

Senzor de imagine

Sensor type CMOS Optical sensor size 1/2 " Progressive scan Yes

Sistem de lentile

Maximum aperture number 4.6 Zoom capability Yes Focal length range 6.91 - 214.64 mm Optical zoom 31 x Digital zoom 12 x Minimum aperture number 1.36 Auto focus Yes

Vizibilitate nocturnă

Night vision Yes LED type IR Night vision distance 400 m Infra-red wavelength 850 nm

Video

Maximum resolution 1920 x 1080 pixels Frame rate 50 fps Video compression formats H.264,H.265,M-JPEG Video streaming Yes Privacy masking Yes Video recording Yes

Reţea

Ethernet LAN Yes Wi-Fi No Supported network protocols IPv4/v6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSb, TLSb, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, LLDP, NTCIP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) Networking standards IEEE 802.1x,IEEE 802.3bt Ethernet interface type Gigabit Ethernet Bluetooth No Quality of Service (QoS) support Yes

Medii de stocare

Built-in HDD No Compatible memory cards SD,SDHC,SDXC Card reader integrated Yes Flash memory 512 MB Internal memory 1024 MB

Conexiune

Ethernet LAN (RJ-45) ports 1

Securitate

Video motion detection Yes HTTPS encryption Yes IP address filtering Yes Password protection Yes Pixel counter Yes Digest authentication Yes Network access storage (NAS) Yes

Managementul energiei

Power source type PoE Power consumption (max) 71 W Power consumption (typical) 25 W AC input voltage 100 - 240 V

Conditii de mediu

Operating temperature (T-T) -50 - 55 °C Storage temperature (T-T) -40 - 65 °C Operating relative humidity (H-H) 10 - 100 %

Greutate şi dimensiuni

Weight 8700 g Height 330 mm Width 313 mm Depth 210 mm

Conţinutul de ambalaje

Number of cameras 1 Cables included LAN (RJ-45) Manual Yes
