Caracteristicile managementului
Quality of Service (QoS) support	Yes
Switch type	Managed

Conexiune

SFP module slots quantity 2 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 8

Reţea

Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3z Copper ethernet cabling technology 1000BASE-T Auto MDI/MDI-X Yes

Transmisie de date

Jumbo frames support Yes MAC address table 4000 entries Switching capacity 20 Gbit/s Forwarding rate 14.88 Mpps Jumbo frames 9000 Store-and-forward Yes Transmission method Store-and-forward

Design

Product colour Black Rack mounting No LED indicators Activity,Link,Power Certification 47 CFR FCC Part 15 Subpart B (Class A), ICES-003 Issue 6 (Class A) EN 61000-4-2 ESD, EN 61000-4-3 RS, EN 61000-4-4 EFT, EN 61000-4-5 Surge, EN 61000-4-6 CS, EN 61000-4-8 IEC 60068-2-27 Shock, • IEC 60068-2-32 Freefall, IEC 60068-2-6 Vibration CE, FCC International Protection (IP) code IP40 Stackable Yes

Performanță

Mean time between failures (MTBF) 392267 h Fanless Yes

Managementul energiei

Power consumption (max) 7.44 W Input current 1 A DC input voltage 12 - 48 V

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Operating temperature (T-T) -20 - 65 °C Operating relative humidity (H-H) 5 - 95 % Storage temperature (T-T) -20 - 85 °C Storage relative humidity (H-H) 5 - 95 %

Greutate şi dimensiuni

Width 190 mm Depth 28 mm Height 100 mm Weight 498 g

Date logistice

Harmonized System (HS) code 85176990
