Procesor
Processor cores	24
Processor family	Intel® Core™ i9
Processor model	i9-14900F
Processor cache	36 MB
Processor threads	32
Processor socket	LGA 1700
Processor operating modes	64-bit
Processor cache type	Smart Cache
Processor boost frequency	5.8 GHz
Processor codename	Raptor Lake
Processor generation	Intel Core i9-14xxx
Stepping	B0
Processor manufacturer	Intel
Memory bandwidth supported by processor (max)	89.6 GB/s
Cooler included	Yes
Box	Yes
Processor ARK ID	236853
Processor base power	65 W
Maximum number of DMI lanes	8
Performance-core base frequency	2 GHz
Performance cores	8
Maximum turbo power	219 W
Performance-core boost frequency	5.4 GHz
Efficient-core base frequency	1.5 GHz
Efficient-core boost frequency	4.3 GHz
Efficient cores	16

Memorie

Memory types supported by processor DDR4-SDRAM,DDR5-SDRAM Maximum internal memory supported by processor 192 GB Memory channels Dual-channel Memory bandwidth (max) 89.6 GB/s

Grafică

On-board graphics card No On-board graphics card model Not available Discrete graphics card No Discrete graphics card model Not available

Caracteristici

Maximum number of PCI Express lanes 20 Scalability 1S Embedded options available No Supported instruction sets AVX 2.0,SSE4.1,SSE4.2 Execute Disable Bit Yes Idle States Yes Thermal Monitoring Technologies Yes PCI Express configurations 1x16+1x4,2x8+1x4 PCI Express slots version 4.0,5.0 Market segment Desktop CPU configuration (max) 1 Export Control Classification Number (ECCN) 5A992C Commodity Classification Automated Tracking System (CCATS) 740.17B1 Use conditions PC/Client/Tablet Direct Media Interface (DMI) Revision 4.0

Caracteristici speciale procesor

Intel Virtualization Technology (VT-x) Yes Intel 64 Yes Enhanced Intel SpeedStep Technology Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel® Turbo Boost Technology 2.0 Intel® Hyper Threading Technology (Intel® HT Technology) Yes Intel® AES New Instructions (Intel® AES-NI) Yes Intel® Secure Key Yes Intel® OS Guard Yes Intel Turbo Boost Max Technology 3.0 Yes Intel® Speed Shift Technology Yes Intel® Volume Management Device (VMD) Yes Intel® Deep Learning Boost (Intel® DL Boost) Yes Mode-based Execute Control (MBE) Yes Intel® Boot Guard Yes Intel® Thermal Velocity Boost Yes Intel® Turbo Boost Max Technology 3.0 frequency 5.6 GHz Intel® Control-flow Enforcement Technology (CET) Yes Intel® Thread Director Yes Intel® Thermal Velocity Boost Frequency 5.8 GHz Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes Intel® Standard Manageability (ISM) Yes Intel® Adaptive Boost Technology Yes

Conditii de mediu

Tjunction 100 °C

Date logistice

Harmonized System (HS) code 8542310001

Detalii tehnice

Status Launched Launch date Q1''24

Greutate şi dimensiuni

Processor package size 45 x 37.5 mm

Alte caracteristici

Maximum internal memory 192 GB L2 cache 32768 KB
