Procesor
Processor cores	2
Processor family	Intel Processor 300
Processor model	300
Processor cache	6 MB
Processor threads	4
Processor socket	LGA 1700
Processor operating modes	64-bit
Processor cache type	Smart Cache
Processor codename	Raptor Lake
Stepping	H0
Processor manufacturer	Intel
Memory bandwidth supported by processor (max)	76.8 GB/s
Cooler included	Yes
Box	Yes
Processor ARK ID	236846
Processor base power	46 W
Maximum number of DMI lanes	8
Performance-core base frequency	3.9 GHz
Performance cores	2

Memorie

Memory types supported by processor DDR4-SDRAM,DDR5-SDRAM Maximum internal memory supported by processor 192 GB Memory channels Dual-channel Memory bandwidth (max) 76.8 GB/s

Grafică

On-board graphics card Yes On-board graphics card model Intel UHD Graphics 710 Discrete graphics card No On-board graphics card base frequency 300 MHz On-board graphics card dynamic frequency (max) 1450 MHz On-board graphics card OpenGL version 4.5 Number of displays supported (on-board graphics) 4 On-board graphics card DirectX version 12.0 Discrete graphics card model Not available On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels On-board graphics card ID 0x4693 On-board graphics card outputs supported Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1 Number of execution units 16 Multi-Format Codec Engines 1

Caracteristici

Maximum number of PCI Express lanes 20 Scalability 1S Embedded options available No Supported instruction sets AVX 2.0,SSE4.1,SSE4.2 Execute Disable Bit Yes Idle States Yes Thermal Monitoring Technologies Yes PCI Express configurations 1x16+1x4,2x8+1x4 PCI Express slots version 4.0,5.0 Market segment Desktop CPU configuration (max) 1 Export Control Classification Number (ECCN) 5A992C Commodity Classification Automated Tracking System (CCATS) 740.17B1 Thermal solution specification PCG 2020C Use conditions PC/Client/Tablet Direct Media Interface (DMI) Revision 4.0

Caracteristici speciale procesor

Intel Virtualization Technology (VT-x) Yes Intel 64 Yes Enhanced Intel SpeedStep Technology Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel® Hyper Threading Technology (Intel® HT Technology) Yes Intel® AES New Instructions (Intel® AES-NI) Yes Intel® Secure Key Yes Intel® OS Guard Yes Intel® Speed Shift Technology Yes Intel® Volume Management Device (VMD) Yes Intel® Deep Learning Boost (Intel® DL Boost) Yes Mode-based Execute Control (MBE) Yes Intel® Boot Guard Yes Intel® Clear Video HD Technology (Intel® CVT HD) Yes Intel® Quick Sync Video Technology Yes Intel® Control-flow Enforcement Technology (CET) Yes Intel® Thread Director No Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes Intel® Standard Manageability (ISM) Yes

Conditii de mediu

Tjunction 100 °C

Date logistice

Harmonized System (HS) code 8542310001

Detalii tehnice

Status Launched Launch date Q1''24 OpenCL version 3.0

Greutate şi dimensiuni

Processor package size 45 x 37.5 mm

Alte caracteristici

Maximum internal memory 192 GB Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1 L2 cache 2560 KB
