Scanare
Maximum scan size	216 x 3000 mm
Optical scanning resolution	600 x 600 DPI
Colour scanning	Yes
Duplex scanning	Yes
ADF scan speed (b/w, A4)	70 ppm
Output colour depth	24 bit
ADF scan speed (colour, A4)	70 ppm
Black/white scanning colour modes	Grayscale
Input colour depth	30 bit
Film scanning	No
Duplex ADF scan speed (b/w, A4)	140 ipm
Output greyscale depth	8 bit
Duplex ADF scan speed (colour, A4)	140 ipm
Greyscale levels	256
Selectable background colour	No
ADF scan speed (greyscale, A4)	70 ppm

Design

Product colour Black,White Scanner type ADF scanner Built-in display Yes Display LCD Touchscreen No Display diagonal 1.5 "

Performanță

Sensor type Dual CIS Scan drivers ISIS,TWAIN,WIA Light source RGB LED Daily duty cycle (max) 7000 pages Scan file formats BMP,CSV,DOC,JPG,PDF,PNG,RTF,TIFF,TXT,XLS Scan to Cloud,E-mail,E-mail Server,File,Image,OCR,PC,TWAIN,WIA Button functions Cancel,Down,Off,On,Scan,Up Barcode reader Yes Built-in processor Yes Processor frequency 1500 MHz

Capacitatea de intrare

Auto document feeder (ADF) input capacity 80 sheets Standard input capacity 80 sheets

Manipularea hârtiei

Maximum ISO A-series paper size A4 Scanning media types supported Plain paper,Plastic Card,Recycled paper,Thick paper,Thin paper Auto Document Feeder (ADF) media weight 27 - 433 g/m² ISO A-series sizes (A0...A9) A4 Minimum scan area (ADF) 52 x 52 mm Multi feed detection Yes Maximum scan area (ADF) 216 x 356 mm Maximum scan length 3000 mm Maximum scan width 216 mm Legal Yes

Conexiune

USB port Yes USB version 3.2 Gen 2 (3.1 Gen 2) Standard interfaces USB 3.2 Gen 1 (3.1 Gen 1)

Managementul energiei

Power supply type AC Input voltage 100-240 V Power consumption (typical) 36 W Power consumption (standby) 3 W Power consumption (off) 0.5 W AC input frequency 50 - 60 Hz Power consumption (PowerSave) 3 W Power supply 36 W

Cerinţe de sistem

Windows operating systems supported Windows 10,Windows 7,Windows 8,Windows 8.1 Minimum RAM 4000 MB Minimum processor INTEL CORE i3 - 4150 processor

Conditii de mediu

Operating relative humidity (H-H) 15 - 80 % Operating temperature (T-T) 10 - 35 °C Operating temperature (T-T) 50 - 95 °F

Certificate

Certification EPEAT Registered ENERGY STAR Qualified AS/NZS CISPR 22:2009 +A1:2010; (Class B RCM mark), CAN / CSA – C22.2 No 60950-1-07 +A1:2011 (TUV C mark), Canada CSA-CISPR 22-10 / ICES-003 Issue 5 (Class B), China GB4943.1:2011; GB9254:2008 Class B (CCC S&E mark), EN55022:2010 ITE Emissions (Class B), EN55024:2010 ITE Immunity (CE mark), EN60950-1:2006 +A1,+A11,+A12 (TUV GS mark), IEC60950-1:2005 +A1, Taiwan CNS 13438:2006 (Class B); CNS 14336-1 (BSMI mark), UL 60950-1:2007 R12.11 (TUV US mark), CFR 47 Part 15 (FCC Class B), Argentina S mark

Greutate şi dimensiuni

Weight 3300 g Depth 204 mm Height 182.5 mm Width 312 mm

Conţinutul de ambalaje

Bundled software WINDOWS Bundled software: TWAIN, ISIS, WIA Drivers; Alaris Capture Pro Limited, Smart Touch, LINUX drivers available from www.kodak.com/go/scanonlinux (September Availability) KOFAX certified. (Future Availability) Cables included AC,USB Drivers included Yes ADF paper chute Yes Stacker Yes

Alte caracteristici

Downloadable software Capture Pro Limited Edition, Smart Touch

Detalii tehnice

Sustainability certificates ENERGY STAR PC connection USB 3.2 Gen 1 (3.1 Gen 1) Linear (1D) barcodes supported Codabar,Code 128,Code 3 of 9,EAN-13,EAN-8,PDF417,U.P.C. Scan technology Dual CIS Maximum paper size 216 x 3000 mm Relative humidity 15 - 80 % Power 36 W

Date logistice

Harmonized System (HS) code 84716070
